O.S Pet I .09 Series 3

Type Model: Glow STD
Engine Size: 1.62cc
Company: O.S Max
Year of Manufacture: 1959
Article Test by: Model Aircraft May 1959

Details:

Publisher:O.S Max
Publishing Year:1959
Edition:Japanese
Keywords:O.S-Engines, O.S-Tests
Rating:5.00 (1Vote(s))
File size:970.1 KB
File Type:PDF Word
File Quality:Clear
Added by:hlsat
File:O.S Pet I .09 Series 3
Link to URL:https://flyinghlsat.com/details.php?publication_id=12358
Mk. 1 Series 3

As Mk. 1 Series 2 but with two extra short screws retaining head for a total of four screws two of which remained long to retain the cylinder. Red-anodized fuel tank. Pressed-in spraybar now knurled for greater security. This variant was the subject of a test which appeared in the May 1959 issue of Model Aircraft. A peak output of 0.138 BHP 15000 RPM was reported. For the first time an RC version of this model was offered. The earliest RC version used a stamped metal venturi cover with pivoting throttle plate. Later examples had a barrel throttle valve inserted into the venturi and retained by the needle valve. The barrel was located upstream of the spraybar thus working by simply enriching the mixture.
